Second Hand

Used, well-preserved control board for wodtke pellet stoves with S2 control.
The control board has been tested and works perfectly.
It comes from a pellet stove that was replaced with a new wodtke model.
€170 including VAT, plus shipping costs
Delivery time: 2-5 working days

Used, fully functional air flow sensor for all wodtke pellet stoves with S2 control.
The LMS has been tested and works perfectly, a new gasket is included.
It comes from a pellet stove that was replaced by a new wodtke model.
€170 including VAT, plus shipping costs
Delivery time: 2-5 working days

The motherboard only ran for 16 days, then the entire device was replaced with a new wodtke pellet stove.
For water-bearing wodtke pellet stoves with 10kW output.
€490 including VAT, plus shipping costs
Delivery time: 2-5 working days

Unused differential pressure controller DS01 from wodtke (was never installed).

The DS01 enables the operation of room air-dependent fireplaces for solid fuels in conjunction with controlled ventilation systems.
When operating at the same time, it must be prevented that the ventilation system creates high negative pressures in the installation room, which could impair the operation of the fireplace or even lead to smoke gas escaping.
The DS01 permanently monitors the differential pressure between the connecting piece of the exhaust system of a room-air-dependent fireplace and the installation room. If the differential pressure falls below a minimum value, the ventilation system is switched off. Monitoring is only active when the fireplace is in operation.
The operating status of the fireplace is determined in different ways:
For fireplaces for logs and lignite briquettes, a temperature measuring adapter ( option* ) is installed in the connecting piece of the fireplace in addition to the pressure measuring adapter. If a minimum temperature is exceeded, the start signal for monitoring is triggered.
With wodtke pellet stoves, the DS01 is connected to the stove's circuit board and directly receives the start signal for monitoring.

*The temperature measuring adapter can be purchased separately.

€300 including VAT, plus shipping costs
Delivery time: 2-5 working days

Used motorized supply air or exhaust gas flap AK1 from wodtke, tightly closing to reduce cooling losses.

The flap was installed in the supply air of a wodtke pellet stove for two years (therefore free of deposits and like new).
It is now no longer needed as the premises are being redesigned.

Suitable for all wodtke pellet primary stoves from S3 control.
It can also be used as a supply air flap (recommendation).
The AK1 is motor controlled and monitored via the control of the pellet primary stoves.
The flap only opens when the primary oven is in operation and thus prevents cooling losses.
The special safety electronics allow a tight-fitting design for solid fuels for the first time.

€280 including VAT, plus shipping costs
Delivery time: 2-5 working days

For pellet stoves with 52mm combustion air intake pipe.
For easy installation of a combustion air line to the outside.
€10 including VAT, plus shipping costs
Delivery time: 2-5 working days
